Material: Svets. konstruktioner Gjutna konstruktioner | St. 37 – | – G. 22 | – – |
Sträckgräns kg/mm 2 . . . | 25 | – | – |
Brottgräns, dragning oD kg/mm2 . . . | 37 | 22 | – |
Brottgräns, tryck kg/mm2 . . . | - | 75 | – |
Elasticitetsmodul kg/mm2 . . . | 20 000 | 10 000 | – |
Godstjocklek mm . . . | Sg | Sg | Ss/Sg |
Dimensionering för: Styvhet, dragning, tryck E . A . . . | 20 000 Ssh | 10 000 Sgh | 0,5 |
Styvhet, böjning E . J . . . | 20 000 Ssh3 | 10 000 Sgh3 | 0,5 |
Styvhet, böjning E . J . . . | 20 000 Ss3h | 10 000 Sg3h | 0,8 |
Hållfasthet, dragning oD . A . . . | 37 Ssh | 22 Sgh | 0,6 |
Hållfasthet, tryck oD . A . . . | 25 Ssh | 75 Sgh | 3,0 |
Hållfasthet, böjning oB . W . . . | 35 Ssh2 | 35 Sgh2 | 1,0 |
Hållfasthet, böjning oB . W . . . | 35 Ss2h | 35 Sg2h | 1,0 |
