17
Fvn. (329 M.). 6.2°. En liden Prøve af graat,
grovkornigt Ler. Mange Stene (veiende indtil 0.6 Gr.),
bestaaende af Kvarts og krystallinske Skifere.
Station 147. N. B. 66° 49’. 0. L. 12° 8’. 142 Fvn.
(260 M.). 6.2.°. Graat, grovkornigt Ler. Faa og ganske
smaa Stene (veiende indtil 0.1 Gr.), bestaaende af
»krystallinske Skifere. I Skraben fandtes mange Stene: Kvarts.
Kvartsskifer. Glimmerskifer, mørk Lerskifer,
Hornblende-skifer. rød Granit og stribet Granit. De største Stene
var tilrundede paa Hjernerne, men ellers temmelig ujeviie;
de mindre var tilrundede paa alle Kanter.
Station 148. N. ß. 67» 27’. 0. L. 13° 25’. 150
Fvn. (274 M.). 5.0°. Graat, blødt Ler.
Station 149. N. B. 67° 52’, 0. L. 13° 58’. 135
Fvn. (247 M.). Graat. lyst. porøst, sandlioldigt Ler med
noget af en mørkere Slags. En liden Sten: Gneis.
Station 150. N. B. 67° li’. 0. L. 13° 21’. 189
Fvn. (346 M.). Graat Ler.
Station 151. X.’ B. 67° 15’. 0. L. 13° 4’. 127
Fvn. (232 M.). Stenbimd.
Station 152. N. B. 67° 18’. 0. L. 12° 46’. 125
Fvn. (229 M.). Haardt, graat, grovkornigt. ensartet Ler
med noget af en løsere Slags. Talrige Glimmerblade. En
liden Sten: Granit (veiende 0.2 Gr.-).
Station 153. N. B. 67° 22’. 0. L. 12° 29’. 122
Fvn. (223 M.). Graat, grovkornigt. uensartet Ler med
talrige Glimmerblade. . Nogle Stene (veiende indtil 0.2 Gr.),
bestaaende af krystallinske Skifere.
Station 154. N. B. 137« 2(3’. 0. L. 12» 14’. 78 Fvn.
(143 M.). Stenbund.
Station 155. N. B. 07» 35’. 0. L. 11» 46’-. 72 Fvn.
(132 M.). 4.4». Stenbund.
Station 156. N. B: 67« 40’. 0. L. 11» 26’. 90
Fvn. (165 M.). 4.7». Stenbund.
Station 157. N. B. 67» 45’. 0. L. 11» 7’. 106 Fvn.
(194 M.). 4.8». Stenbund.
Station 158. N. B. 67» 49’. 0. L. 10» 49’. 102
Den norske Nordhavsexpedition Schmelck: Chemi.
d. 180 fms. (329 ni.); b.-t. 6.2°. A small sample of grey,
coarse clay containing many pebbles (the largest weighing
0.6 ♂r) of quartz and crystalline schists.
Station 147. — Lat. 66° 49’ K, long. 12° 8’ E.: d.
142 fms. (260 m.); b.-t. 6.2°. A grey. coarse clay
containing only a few small pebbles (the largest weighing
0.1’"") of crystalline schists. The dredge brought up
numerous .stones and pebbles, consisting of quartz,
quartz-schist. mica-schist, dark clay-slate, hornblende-schist, red
granite, and striped granite. The large stones were
rounded at the corners, but otherwise comparatively
irregular in form, whereas the small ones had all the sides
rounded.
Station 148. — Lat. 67° 27’ N., long. 13° 25’ E.;
d. 150 fms. (274 m.); b.-t. 5.0°. A grey, soft clay.
Station 149. — Lat. 67° 52’ K, long. 13° 58’ E.;
d. 135 fms. (247 m.). A light-grey, porous, sandy clay
mixed with a little of a darker kind; it contained a small
fragment of gneiss.
Station 150. — Lat. 67° 11’ N.. long. 13° 21’ E.;
d. 189 fms. (346 m.). A grey clay.
Station 151. — Lat. 67° 15’ N.. long. 13° 4’ E.; d.
127 fms. (232 m.). Bottom stony.
Station 152. — Lat. 67° 18’ N.. long. 12° 46’ E.;
d. 125 fins. (229 in.). A hard, coarse, homogeneous, grey
clay mixed with some comparatively porous; it contained
numerous scales of mica, and a small fragment of granite
weighing 0.2"’’.
Station 153. — Lat. 67° 22’ N., long. 12° 29’ E.;
d. 122 fms. (223 in.). A grey,, coarse clay containing
numerous scales of mica and a few- pebbles (the largest
weighing 0.2 ♂r) of crystalline schists.
Station 154. — Lat. 67° 26’ N., long. 12° 14’ E.;
d. 78 fms. (143 m.). Bottom stony.
Station 155. — Lat. 67° 35’ N.. long. 11° 46’ E.;
d. 72 fms. (132 m.); b.-t. 4.4°. Bottom stony.
Station 156. — Lat. 67° 40’ N., long. 11° 26’ E.;
d. 90 fms. (165 m.); b.-t. 4.7°. Bottom stony.
Station 157. — Lat. 67° 45’ K. long. 11° 7’ E,; d.
106 fms. (194 m.); b.-t. 4.8°. Bottom stony.
Station 158. — Lat. 67° 49’ N., long. 10° 49’ E.:
3
